NA-05

Aluminum honeycomb panels utilize a sandwich-type composite structure:

Face/Base Plate: Manufactured from high-strength 3003/5052 series aluminum alloy sheet, with surface treatments including fluorocarbon coating and polyester varnish, providing weather and corrosion resistance and facilitating cleaning.

Center Layer: The core consists of a hexagonal aluminum honeycomb structure (0.04–0.06 mm thick aluminum sheet), formed by lamination from aerospace-grade aluminum, ensuring structural stability and uniform stress distribution.

Composition Process: Employs a two-component, high-temperature curing polyurethane adhesive, hot-pressed for strong adhesion, preventing delamination and warping.

Core Advantages:
1. Lightweight and High Strength, Reduced Load: With a density of only 1/5–1/6 that of traditional panels, but with a strength more than 1.5 times greater than that of common aluminum sheets, it significantly reduces the load on the building/roof and improves installation safety.

2. Ultra-High Flatness, Reduced Tendency to Warp: The honeycomb structure distributes stress evenly, maintaining flatness even in large panels. Synchronized thermal expansion and contraction prevent warping and cracking with prolonged use.

3. Sound and Thermal Insulation, Comfort and Energy Savings: The honeycomb cavity forms a multi-layered air barrier, achieving sound insulation of up to 60 dB. Its excellent thermal resistance effectively reduces noise, provides insulation, and saves energy.

4. Fire-Retardant and Moisture-Resistant, Safe and Durable: Made entirely of non-combustible A2-grade aluminum, it produces no smoke or toxicity in case of fire. It is waterproof, moisture-resistant, mold-resistant, and insect-resistant, with a long lifespan.

5. Eco-friendly and formaldehyde-free, ready to use: Formaldehyde-free, odorless, recyclable, and compliant with sustainable building material standards, ideal for sensitive environments such as hospitals, schools, and homes.

6. Easy installation and highly adaptable: Modular design, easy to cut and join, adaptable to various installation methods such as keels/suspension brackets, customizable size and color, and highly decorative.
